Introduction of Hxdwh AC servo motor:

1. Hxdwh is the first factory specializing in the production of AC servo motor in China, with more than 30 years of R & D and production history of servo motor;

2. Complete product specifications, motor power from 0.2KW to 11.7kw (220v-380v);

3. Stable quality, excellent performance and high cost performance. The products are widely used in various occasions of motion control.

Product series:

HB Series ac servo motors:

Frame size -mm : 110.130.150.180

Rated torque -NM: 2-55

Rated power -Kw:0.6-8.6

Rated speed -RPM:1500.2000.2500.3000

Maximum speed -RPM:/

number of pole-pairs: 4

The feedback element: Incremental Encoder 2500C/T

Electric brake: can match

Fit drive working voltage -VA : 380

HMB Series ac servo motors:

Frame size-mm : 110.130.150.180

Rated torque -NM :4.8-55

Rated power -Kw :0.85-8.6

Rated speed -RPM :1500,2000

number of pole-pairs: 4

The eedback element: Absolute photoelectric encoder (17bit)

Electric brake: can match

Fit drive working voltage -VAC :380

Servo Motor  model:

380V-400V HB Series ac servo motor- 2500C/T incremental encoder

1380V-400V HB Series ac servo motor- 2500C/T incremental encoder

150ST-M15025HFB 380V 3.8KW 11.5A 15NM 2500RPM

150ST-M18020HFB 380V 3.6KW 10.5A 18NM 2000RPM

150ST-M23020HFB 380V 4.7KW 13.5A 23NM 2000RPM

150ST-M27020HFB 380V 5.5KW 13.5A 27NM 2000RPM

380V-400V HBB Series ac servo motor- 17bit absolute value encoder

150ST-M15025HMBB 380V 3.8KW 11.5A 15NM 2500RPM

150ST-M18020HMBB 380V 3.6KW 10.5A 18NM 2000RPM

150ST-M23020HMBB 380V 4.7KW 13.5A 23NM 2000RPM

150ST-M27020HMBB 380V 5.5KW 13.5A 27NM 2000RPM

Application of servo motor:

Applied to woodworking machinery

Applied to dispensing machine equipment

Applied to engraving machine

Applied to glass machinery

Applied to printing equipment
